Cisco Small Business Pro AP 541N Wireless Access Point.

The Cisco AP 541N is a 802.11n dual-band clustering access point built for small businesses. The clustering capability makes it easy to set up, configure, and manage a growing wireless network. You can deploy multiple access points and push a single configuration to all the devices within the cluster, managing your wireless network as a single system without worrying about interference between access points, and without having to configure each access point as a separate device.

The Cisco AP 541N is a versatile, high-performance wireless solution that supports virtually any wireless application your business requires, including mobile data, voice over wireless LAN, wireless video monitoring, and highly secure guest access. It can be used as a standalone access point in small wireless environments or deployed as part of a larger data and communications network, such as the Cisco Smart Business Communication System (SBCS). Designed to integrate with other solutions in the Cisco Small Business Pro series, it makes even advanced wireless and communications applications easy to install, configure, and support.

Specifications:

General:

• Device Type: Wireless access point
• Width: 11.9 in.
• Depth: 7.1 in.
• Height: 1.7 in.
• Weight: 2.9 lbs.
• Localization: Canada, United States.

Processor / Memory / Storage:

• RAM Installed ( Max ): 64 MB.
• Flash Memory Installed (Max): 32 MB.
• Hard Drive: None.

Networking:

• Form Factor: External.
• Connectivity Technology: Wireless.
• Data Transfer Rate: 300 Mbps.
• Data Link Protocol: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n (draft 2.0).
• Spread Spectrum Method: OFDM, DSSS.
• Remote Management Protocol: SNMP 1, SNMP 2, SNMP 3.
• Frequency Band: 2.4 GHz, 5 GHz.
• Status Indicators: Port status, port transmission speed, power.
• Features: DHCP support, load balancing, VLAN support, Syslog support, firmware upgradable, MIMO technology, Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), wireless bridge mode, clustering technology.
• Encryption Algorithm: 64-bit WEP, WPA-PSK, 128-bit AES, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise.
• Authentication Method: RADIUS, Basic Service Set Identifier (BSSID).
• Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11d, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11n (draft 2.0).

Antenna:

• Antenna: External detachable.
• Antenna Qty: 3.
• Directivity: Omni-directional.
• Gain Level: 2 dBi.

Expansion / Connectivity:

• Interfaces: 1 x network / power - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45.
• Miscellaneous:
• Cables Included: 1 x network cable.
• Compliant Standards: CE, EN 300.328, EN 301.489.1, EN 301.489.17, RSS-210, IC, ICES-003 Class A, FCC, UL 60950-1, IEC 60950-1, EN 60950-1, AS/NZS 4268, EN 301.893.

Power:

• Power Over Ethernet (PoE) Supported: Yes.
• Power Device: Power adapter - external.
• Voltage Required: AC 120/230 V ( 50/60 Hz ).
• Software / System Requirements: OS Provided Linux.

Manufacturer Warranty:

• Service & Support: Limited lifetime warranty.
• Service & Support Details: Limited warranty - replacement - lifetime.

1 year Warranty.
