HILTI CP 653 4" FIRESTOP SPEED SLEEVE
Featured Products
HILTI CP 653 4" FIRESTOP SPEED SLEEVE
Part # 2365151 / 2097883
In Stock
Special Price2131
$526.00
Regular Price
$528.00
- Buy 2 for $524.00 each and save 0%
- Buy 3 for $522.00 each and save 1%
- Buy 5 for $520.00 each and save 1%
- Buy 10 for $498.00 each and save 5%
- Buy 20 for $496.00 each and save 6%
- Buy 30 for $494.00 each and save 6%
- Buy 50 for $492.00 each and save 6%
Hilti CP 653 4" Firestop Speed Sleeve.
Features:
- Functional and compliant when properly installed
- Twist-to-close mechanism – for easier and remote re-penetration while protecting cables
- Straightforward inspection – you can see if the sleeve is closed without having to check behind a covering fringe above the ceiling
- Superior smoke tightness and airflow control thanks to its twisting mechanism
- Smoke gaskets eliminate need for sealant or putty
- Can be connected end to end
Applications:
- Firestopping cable penetrations for single and bundled cables
- Suitable for small to medium-sized circular openings in walls, ceilings and floors
- For use on concrete, masonry and drywall
Technical Data:
- Outside diameter: 4.3 in
- Base materials: Concrete, Masonry, Drywall
- Corebit diameter: mm
- Temperature resistance range: -22 - 212 °F
- Mold and mildew resistant: Yes
- Expansion temperature (Approx.): 320 °F
- Expansion ratio (unrestricted, up to): 1:19
- Shelf life Not relevant: 1
- Overall length: 12 in
- Max. core bit diameter: mm
- Outside diameter (flange): 6.7 in
- Storage and transportation temperature range: 23 - 122 °F
- California State fire marshal approval: CSFM Listing 4485-1200:0138 for CP 653 Speed Sleeve
- Mold and mildew performance: Class 0 (ASTM G21-96)
- Application temperature range: 23 - 122 °F
- Smoke resistance: Yes
- Seismic resistant: Yes
- Intumescent: Yes
1 at 77°F/25°C and 50% relative humidity; from date of manufacture
CommGear can install and service at an additional charge.
Additional Information
| Part # | 2365151 / 2097883 |
|---|---|
| MFR | HILTI |
Details
Hilti CP 653 4" Firestop Speed Sleeve.
Features:
- Functional and compliant when properly installed
- Twist-to-close mechanism – for easier and remote re-penetration while protecting cables
- Straightforward inspection – you can see if the sleeve is closed without having to check behind a covering fringe above the ceiling
- Superior smoke tightness and airflow control thanks to its twisting mechanism
- Smoke gaskets eliminate need for sealant or putty
- Can be connected end to end
Applications:
- Firestopping cable penetrations for single and bundled cables
- Suitable for small to medium-sized circular openings in walls, ceilings and floors
- For use on concrete, masonry and drywall
Technical Data:
- Outside diameter: 4.3 in
- Base materials: Concrete, Masonry, Drywall
- Corebit diameter: mm
- Temperature resistance range: -22 - 212 °F
- Mold and mildew resistant: Yes
- Expansion temperature (Approx.): 320 °F
- Expansion ratio (unrestricted, up to): 1:19
- Shelf life Not relevant: 1
- Overall length: 12 in
- Max. core bit diameter: mm
- Outside diameter (flange): 6.7 in
- Storage and transportation temperature range: 23 - 122 °F
- California State fire marshal approval: CSFM Listing 4485-1200:0138 for CP 653 Speed Sleeve
- Mold and mildew performance: Class 0 (ASTM G21-96)
- Application temperature range: 23 - 122 °F
- Smoke resistance: Yes
- Seismic resistant: Yes
- Intumescent: Yes
1 at 77°F/25°C and 50% relative humidity; from date of manufacture
CommGear can install and service at an additional charge.
