MOBOTIX L160 DAY LENS FOR S15D/M15D (NEW)
Featured Products
MOBOTIX L160 DAY LENS FOR S15D/M15D (NEW)
Lenses from Super Wide Angle (90°) to Tele (15°) for all MOBOTIX cameras.
|
Lens |
Type |
Angle |
Focal Length |
Image width |
|
[H x V] |
≙ 35mm equivalent |
[in a distance of 10 m] |
||
|
L25 |
Super Wide Angle 82° |
82° x 61° |
f = 4 mm (≙ 25 mm) |
17.4 m x 11.9 m |
|
L38 |
Wide Angle 55° |
55° x 41° |
f = 6 mm (≙ 38 mm) |
10.3 m x 7.3 m |
|
L51 |
Wide Angle 40° |
40° x 30° |
f = 8 mm (≙ 51 mm) |
7.2 m x 5.4 m |
|
L76 |
Tele 27° |
27° x 20° |
f = 12 mm (≙ 76 mm) |
4.9 m x 3.6 m |
|
L160 |
Tele 13° |
13° x 10° |
f = 25 mm (≙ 160 mm) |
2.3 m x 1.7 m |
|
L320 |
Tele 7° |
7° x 5° |
f = 50 mm (≙ 320 mm) |
1.1 m x 0.9 m |
Note: In the color sensors, the infrared CUT filter is NOT in the lens, but rather already installed in the lens casing in the camera.
Installation and service in North Carolina only. Preprogramming can be done before shipping to site.
| Part # | MX-SM-D160-PW |
|---|---|
| MFR | MOBOTIX |
