MOBOTIX M16 LICENSE PLATE RECOGNITION WEATHERPROOF DUAL M16 CAMERA WITH 45° (B079) LPF LENS & 45° (B079) LENS (NEW)

Mobotix Security Cameras

MOBOTIX M16 LICENSE PLATE RECOGNITION WEATHERPROOF DUAL M16 CAMERA WITH 45° (B079) LPF LENS & 45° (B079) LENS (NEW)

Part # Mx-M16B / Mx-O-SMA-S-6L079 / Mx-A-IRA-45
In Stock
$2,187.00
- +

Dual. Modular. Unique.

True to the original: Weatherproof and robust, the latest successor to our successful M1 through M12 dual camera models features interchangeable sensor modules as well as the latest MOBOTIX system technology. The result is a product completely unrivaled in terms of performance, functionality and design.

The MxBus functionality, developed by MOBOTIX, makes it possible to connect additional modules, such as the Mx GPS box as a time server. MxBus helps achieve a complete all around video security system.

Advantages of the camera line Mx6

M16 AllroundDual, M16 Thermal/Thermal TR, S16 DualFlex, V16 Vandalism

  • Micro Processor: Dual Core
  • Image Sensor(s): 1/1.8“ CMOS, 6MP (3072 x 2048), Progessive Scan, color or B/W
  • Max. Image Size per sensor: 6 MP (3072 x 2048 pixels)
  • Max. Frame Rate (MxPEG): 42@HD, 34@FullHD (1920 x 1080), 12@6MP, 6@2x 6MP
  • H.264 Hardware Codec: Yes, bandwidth adjustment possible; output format max. QXGA
  • ONVIF Support: Yes, full Profil S support with future software update
  • Multicast-Stream via RTSP: Possible with H.264, MxPEG and MJPEG
  • Multi-Streaming: Yes
  • Power supply: PoE, power supply typ. < 5 watts
  • Mini USB Interface: Yes
  • Receive/Send MxMessages: Yes



Features:

  • M16 camera module for connecting one or two M16/M15 sensor modules (to be ordered individually)
  • ONVIF-compliant Mx6 system platform (2nd generation) with H.264, MxPEG+ and M-JPEG
  • Image sensor options (via sensor module): 5 or 6 megapixels, color (day) and/or B/W (night)
  • Lens options (via sensor module): horizontal image angle from 180° to 8°
  • Max. image size (per image sensor): 6MP (3072 x 2048 pixels)
  • Operating conditions: IP66/IK07, -40 to 60°C (-40 to 140°F)
  • Internal DVR: 4 GB microSD
  • System components: speaker and microphone (inside housing), PIR sensor, temperature sensor, MxActivitySensor, shock detector
  • VarioFlex wall/ceiling mount (can be used with additional pole mount: MX-MH-SecureFlex-ESWS), ethernet patch cable 0.5 m/1.65 ft
  • Interfaces: Ethernet 10/100 (RJ45), MxBus, USB; IO and RS232 via additional MX Interface Box
  • Incl. 1 Blind Module (MX-SM-Blind-PW)



Includes:

  • Qty. (1) Mx-M16 Allround Dual Security Camera with MxBus (Body Onoly - No Lenses) #Mx-M16B.
  • Qty. (1) Mx-O-SMA-S-6L079 (B079 45° 6MP Night LPF Lens).
  • Qty. (1) Mx-O-SMA-S-6D079 (B079 45° 6MP Day Lens).
  • Qty. (1) Mx-A-IRA-45 (MxIRLight Infrared Illuminator 45° x 45°).
  • Qty. (1) Mx-M-IRA-ML (MxIRLight Mounting Brackets for M1x).
  • Qty. (1) MX-Overvoltage-Protection-Box-RJ45 (Network Connector With Surge Protection, RJ45 Version).



MxIRLight Infrared Illuminator (860 nm), 45°x45°.

Features:

  • Infrared illuminator with 45° illumination angle (horizontal and vertical), aluminum housing
  • 860 nm
  • IP67
  • Range: up to 80 m (262 ft.)
  • PoE+ power supply via network cable (IEEE 802.3at), 19 W (max.) power consumption
  • Photosensor for automatic switching on/off (threshold value: 3 lux, delay for switching off: 150 s)
  • Including standard mount for installing on wall and ceiling, screws, preassembled 0.9 m patch cable with RJ45 connector and MOBOTIX special sealing ring
  • Optional accessories: mounting brackets for M1x/M2x (Mx-M-IRA-ML/Mx-M-IRA-M)
  • Housing color: white



Weatherproof dual network camera with megapixel resolution and two super-wide angle, wide-angle or telephoto lenses with a color or black-and-white sensor for use around the clock. Depending on the lighting conditions, the camera automatically switches between the color sensor with the daylight lens and the more light-sensitive black-and-white lens. Integrates all MOBOTIX functions.

Day + Night sensor: Tele 135mm



Learn More

Installation and service in North Carolina only. Preprogramming can be done before shipping to site.

Additional Information
More Information
Part # Mx-M16B / Mx-O-SMA-S-6L079 / Mx-A-IRA-45
MFR MOBOTIX
Details

Dual. Modular. Unique.

True to the original: Weatherproof and robust, the latest successor to our successful M1 through M12 dual camera models features interchangeable sensor modules as well as the latest MOBOTIX system technology. The result is a product completely unrivaled in terms of performance, functionality and design.

The MxBus functionality, developed by MOBOTIX, makes it possible to connect additional modules, such as the Mx GPS box as a time server. MxBus helps achieve a complete all around video security system.

Advantages of the camera line Mx6

M16 AllroundDual, M16 Thermal/Thermal TR, S16 DualFlex, V16 Vandalism

  • Micro Processor: Dual Core
  • Image Sensor(s): 1/1.8“ CMOS, 6MP (3072 x 2048), Progessive Scan, color or B/W
  • Max. Image Size per sensor: 6 MP (3072 x 2048 pixels)
  • Max. Frame Rate (MxPEG): 42@HD, 34@FullHD (1920 x 1080), 12@6MP, 6@2x 6MP
  • H.264 Hardware Codec: Yes, bandwidth adjustment possible; output format max. QXGA
  • ONVIF Support: Yes, full Profil S support with future software update
  • Multicast-Stream via RTSP: Possible with H.264, MxPEG and MJPEG
  • Multi-Streaming: Yes
  • Power supply: PoE, power supply typ. < 5 watts
  • Mini USB Interface: Yes
  • Receive/Send MxMessages: Yes



Features:

  • M16 camera module for connecting one or two M16/M15 sensor modules (to be ordered individually)
  • ONVIF-compliant Mx6 system platform (2nd generation) with H.264, MxPEG+ and M-JPEG
  • Image sensor options (via sensor module): 5 or 6 megapixels, color (day) and/or B/W (night)
  • Lens options (via sensor module): horizontal image angle from 180° to 8°
  • Max. image size (per image sensor): 6MP (3072 x 2048 pixels)
  • Operating conditions: IP66/IK07, -40 to 60°C (-40 to 140°F)
  • Internal DVR: 4 GB microSD
  • System components: speaker and microphone (inside housing), PIR sensor, temperature sensor, MxActivitySensor, shock detector
  • VarioFlex wall/ceiling mount (can be used with additional pole mount: MX-MH-SecureFlex-ESWS), ethernet patch cable 0.5 m/1.65 ft
  • Interfaces: Ethernet 10/100 (RJ45), MxBus, USB; IO and RS232 via additional MX Interface Box
  • Incl. 1 Blind Module (MX-SM-Blind-PW)



Includes:

  • Qty. (1) Mx-M16 Allround Dual Security Camera with MxBus (Body Onoly - No Lenses) #Mx-M16B.
  • Qty. (1) Mx-O-SMA-S-6L079 (B079 45° 6MP Night LPF Lens).
  • Qty. (1) Mx-O-SMA-S-6D079 (B079 45° 6MP Day Lens).
  • Qty. (1) Mx-A-IRA-45 (MxIRLight Infrared Illuminator 45° x 45°).
  • Qty. (1) Mx-M-IRA-ML (MxIRLight Mounting Brackets for M1x).
  • Qty. (1) MX-Overvoltage-Protection-Box-RJ45 (Network Connector With Surge Protection, RJ45 Version).



MxIRLight Infrared Illuminator (860 nm), 45°x45°.

Features:

  • Infrared illuminator with 45° illumination angle (horizontal and vertical), aluminum housing
  • 860 nm
  • IP67
  • Range: up to 80 m (262 ft.)
  • PoE+ power supply via network cable (IEEE 802.3at), 19 W (max.) power consumption
  • Photosensor for automatic switching on/off (threshold value: 3 lux, delay for switching off: 150 s)
  • Including standard mount for installing on wall and ceiling, screws, preassembled 0.9 m patch cable with RJ45 connector and MOBOTIX special sealing ring
  • Optional accessories: mounting brackets for M1x/M2x (Mx-M-IRA-ML/Mx-M-IRA-M)
  • Housing color: white



Weatherproof dual network camera with megapixel resolution and two super-wide angle, wide-angle or telephoto lenses with a color or black-and-white sensor for use around the clock. Depending on the lighting conditions, the camera automatically switches between the color sensor with the daylight lens and the more light-sensitive black-and-white lens. Integrates all MOBOTIX functions.

Day + Night sensor: Tele 135mm



Learn More

Installation and service in North Carolina only. Preprogramming can be done before shipping to site.
