MOBOTIX S16 FLEXMOUNT CORE WITH MXBUS (NEW)
Mobotix Outdoor Cameras
MOBOTIX S16 FLEXMOUNT CORE WITH MXBUS (NEW)
- Buy 20 for $850.00 each and save 5%
The MxBus functionality, developed by MOBOTIX, makes it possible to connect additional modules, such as the Mx GPS box as a time server. MxBus helps achieve a complete all around video security system.
Mobotix S16 FlexMount Core
- Housing without sensor module(s)
- Features one or two sensor modules
- Suitable for mounting behind a wall or ceiling
- Robust and maintenance-free, without moving parts
Advantages of the camera line Mx6
M16 AllroundDual, M16 Thermal/Thermal TR, S16 DualFlex, V16 Vandalism
- Micro Processor: Dual Core
- Image Sensor(s): 1/1.8“ CMOS, 6MP (3072 x 2048), Progessive Scan, color or B/W
- Max. Image Size per sensor: 6 MP (3072 x 2048 pixels)
- Max. Frame Rate (MxPEG): 42@HD, 34@FullHD (1920 x 1080), 12@6MP, 6@2x 6MP
- H.264 Hardware Codec: Yes, bandwidth adjustment possible; output format max. QXGA
- ONVIF Support: Yes, full Profil S support with future software update
- Multicast-Stream via RTSP: Possible with H.264, MxPEG and MJPEG
- Multi-Streaming: Yes
- Power supply: PoE, power supply typ. < 5 watts
- Mini USB Interface: Yes
- Receive/Send MxMessages: Yes
Features:
- S16 camera module (body) for connecting one or two S16/S15 sensor modules (to be ordered individually)
- ONVIF-compliant Mx6 system platform (2nd generation) with H.264, MxPEG+ and M-JPEG
- Image sensor options (via sensor module): 6 megapixels, color (day) and/or B/W (night) and/or thermal
- Lens options (via optical sensor module): horizontal image angle from 180° to 8°
- IP66/IK06, -40 to 60°C (-40 to 140°F)
- Internal DVR: 4 GB microSD
- System components: temperature sensor, MxActivitySensor, shock detector
- Ethernet patch cable 0.5 m/1.65 ft
- Interfaces: 2x connection for MOBOTIX sensor module (Cam1/Cam2), Ethernet 10/100 (RJ45 and LSA), MxBus, USB, Audio (I/O); RS232 via MX Interface Box
Do you need Lenses? CommGear sells them.
Installation and service in North Carolina only. Preprogramming can be done before shipping to site.
Replaces S15.
| Part # | Mx-S16B |
|---|---|
| MFR | MOBOTIX |
The MxBus functionality, developed by MOBOTIX, makes it possible to connect additional modules, such as the Mx GPS box as a time server. MxBus helps achieve a complete all around video security system.
Mobotix S16 FlexMount Core
- Housing without sensor module(s)
- Features one or two sensor modules
- Suitable for mounting behind a wall or ceiling
- Robust and maintenance-free, without moving parts
Advantages of the camera line Mx6
M16 AllroundDual, M16 Thermal/Thermal TR, S16 DualFlex, V16 Vandalism
- Micro Processor: Dual Core
- Image Sensor(s): 1/1.8“ CMOS, 6MP (3072 x 2048), Progessive Scan, color or B/W
- Max. Image Size per sensor: 6 MP (3072 x 2048 pixels)
- Max. Frame Rate (MxPEG): 42@HD, 34@FullHD (1920 x 1080), 12@6MP, 6@2x 6MP
- H.264 Hardware Codec: Yes, bandwidth adjustment possible; output format max. QXGA
- ONVIF Support: Yes, full Profil S support with future software update
- Multicast-Stream via RTSP: Possible with H.264, MxPEG and MJPEG
- Multi-Streaming: Yes
- Power supply: PoE, power supply typ. < 5 watts
- Mini USB Interface: Yes
- Receive/Send MxMessages: Yes
Features:
- S16 camera module (body) for connecting one or two S16/S15 sensor modules (to be ordered individually)
- ONVIF-compliant Mx6 system platform (2nd generation) with H.264, MxPEG+ and M-JPEG
- Image sensor options (via sensor module): 6 megapixels, color (day) and/or B/W (night) and/or thermal
- Lens options (via optical sensor module): horizontal image angle from 180° to 8°
- IP66/IK06, -40 to 60°C (-40 to 140°F)
- Internal DVR: 4 GB microSD
- System components: temperature sensor, MxActivitySensor, shock detector
- Ethernet patch cable 0.5 m/1.65 ft
- Interfaces: 2x connection for MOBOTIX sensor module (Cam1/Cam2), Ethernet 10/100 (RJ45 and LSA), MxBus, USB, Audio (I/O); RS232 via MX Interface Box
Do you need Lenses? CommGear sells them.
Installation and service in North Carolina only. Preprogramming can be done before shipping to site.
Replaces S15.
