PERLE S-1000MM-S2SC10 - MM MEDIA CONVERTER
Media Converters
PERLE S-1000MM-S2SC10 - MM MEDIA CONVERTER
- Buy 2 for $1,080.00 each and save 1%
Perle S-1000-S2SC10 - Media Converter
S-1000MM-S2SC10 - Gigabit Ethernet Fiber to Fiber Stand-Alone Media Converter.
1000Base-SX 850nm multimode (SC) [550 m/1804 ft.] to 1000Base-LX/LH 1310 nm single mode (SC) [10 km/6.2 miles].
Specifications:
General:
- Device Type: Media converter
- Form Factor: Plug-in module
Networking
- Connectivity Technology: Wired
- Cabling Type: 1000Base-LX, 1000Base-SX, 1000Base-LH
- Data Link Protocol: Gigabit Ethernet
- Data Transfer Rate: 1 Gbps
- Optical Wave Length: 850 nm / 1310 nm
- Max Transfer Distance: 6.2 miles
- Status Indicators: Link activity, power, receive
- Features: FiberAlert, auto-negotiation, VLAN support, half duplex mode, full duplex mode
- Compliant Standards: IEEE 802.3, IEEE 802.1Q, IEEE 802.3x
Expansion / Connectivity
- Interfaces: 1 x Ethernet 1000Base-SX - SC multi-mode female x 2 ¦ 1 x Ethernet 1000Base-LX/1000Base-LH - SC single mode female x 2
- Compatible Slots: 1 x expansion slot
Miscellaneous
- MTBF: 421,344 hours
- Compliant Standards: CISPR 22 Class A, EN 60950, EN 61000-3-2, EN55024, EN55022 Class A, RoHS, UL 60950-1, WEEE, FCC Part 15 A, REACH, EN 60825-1
Dimensions & Weight
- Weight: 5.29 oz
Manufacturer Warranty
- Service & Support: Limited lifetime warranty
- Service & Support Details: Limited warranty - lifetime
Environmental Parameters
- Min Operating Temperature: 32 °F
- Max Operating Temperature: 122 °F
- Humidity Range Operating: 5 - 90% (non-condensing)
1 year Warranty.
Do you need Patch Cables? CommGear sells them. Install and service at an additional charge.
