BOSE DESIGNMAX DM5C 5.25" 2-WAY INDOOR IN-CEILING SPEAKERS (WHITE) (PAIR)
Featured Products
BOSE DESIGNMAX DM5C 5.25" 2-WAY INDOOR IN-CEILING SPEAKERS (WHITE) (PAIR)
- Buy 2 for $605.00 each and save 1%
- Buy 4 for $600.00 each and save 2%
- Buy 10 for $595.00 each and save 2%
- Buy 20 for $590.00 each and save 3%
- Buy 30 for $585.00 each and save 4%
- Buy 50 for $580.00 each and save 5%
- Buy 75 for $575.00 each and save 6%
- Buy 100 for $570.00 each and save 7%
With coaxial two-way drivers, the 60-watt DesignMax DM5C loudspeaker offers rich lows and clear, intelligible highs — along with premium aesthetics that complement any commercial sound installation. The DM5C features a two-way 5.25-inch woofer and 1-inch coaxial tweeter mounted within the Dispersion Alignment system, delivering a frequency range of 65 Hz – 20 kHz. The in-ceiling DM5C is installed easily via QuickHold mounting arms.
For indoor applications only.
EN 54-24 compliant DS loudspeaker models are also available for use in Voice Alarm (VA) systems. Please contact your local Bose team for availability information.
Features:
- Frequency Response (+/-3 dB): 73 - 17,000 Hz
- Nominal coverage (H x V): 130° Conical
- Power Handling, peak: 240 W
- Maximum SPL @ 1m: 105 dB
- Frequency Range (-10 dB): 65 - 20,000 Hz
- Power Handling, long-term continuous: 60 W
- Sensitivity (SPL/1W @ 1 m): 87 dB
- Nominal Impedance: 8 Ω (transformer bypass)
Do you need an Ampilifer? CommGear sells it. Install and service at an additional charge.
| Part # | 829683-0210 |
|---|---|
| MFR | BOSE |
With coaxial two-way drivers, the 60-watt DesignMax DM5C loudspeaker offers rich lows and clear, intelligible highs — along with premium aesthetics that complement any commercial sound installation. The DM5C features a two-way 5.25-inch woofer and 1-inch coaxial tweeter mounted within the Dispersion Alignment system, delivering a frequency range of 65 Hz – 20 kHz. The in-ceiling DM5C is installed easily via QuickHold mounting arms.
For indoor applications only.
EN 54-24 compliant DS loudspeaker models are also available for use in Voice Alarm (VA) systems. Please contact your local Bose team for availability information.
Features:
- Frequency Response (+/-3 dB): 73 - 17,000 Hz
- Nominal coverage (H x V): 130° Conical
- Power Handling, peak: 240 W
- Maximum SPL @ 1m: 105 dB
- Frequency Range (-10 dB): 65 - 20,000 Hz
- Power Handling, long-term continuous: 60 W
- Sensitivity (SPL/1W @ 1 m): 87 dB
- Nominal Impedance: 8 Ω (transformer bypass)
Do you need an Ampilifer? CommGear sells it. Install and service at an additional charge.
